RCI 3513/3513DM Cabinet Lock

The 3513 & 3513DM cabinet locks are designed for small enclosures where power is available. These compact surface-mounted electric locks are versatile for side or top mounting. The RCI 3513DM adds an option for dual monitoring to the standard electromechanical RCI 3513 cabinet lock.

Get in touch
3513 Cabinet Lock Specialty Locks RCI EAD
  • Energy: 200mA Field-Selectable 12/24VDC (Max at 12VDC, 100mA at 24VDC)
  • Strength: 440lbf Holding Force
  • Mode: Field-Selectable Fail-Safe & Fail-Secure
  • Monitoring: Optional Dual Monitoring Model Available
  • Warranty: 3 Year Limited Warranty

Product Details

  • Surface-mounted compact electric lock
  • Superior heavy-duty metal construction
  • Versatile side or top mounting
  • Low energy consumption
  • Positioning of the solenoid determines lock mode
  • Black finish
  • 200mA Field-Selectable 12/24VDC (Max at 12VDC, 100mA at 24VDC)
  • 440lbf Holding Force
  • Field-Selectable Fail-Safe & Fail-Secure
  • Optional Dual Monitoring Model Available
  • 3 Year Limited Warranty

Technical Details

3513 Electromechanical Cabinet Lock
Dimensions: 1-3/16" W x 2-7/8" H x 1-1/8" D (30mm x 73mm x 29mm)

3513DM Electromechanical Cabinet Lock with Monitoring
Dimensions: 1-3/16" W x 3-11/16" H x 1-1/4" D (30mm x 94mm x 32mm)

Applications

  • Small Interior Enclosures
  • Filing Cabinets
  • Drug Cabinets
  • Jewelry Cases
  • Showcases
  • Key Cabinets
  • Desk Drawers
  • Cash Drawers
  • Machine Access
  • Vending Machines Covers
3513 Cabinet Lock Specialty Locks RCI EAD
3513DM Cabinet Lock Specialty Locks RCI EAD
