Descripción del producto

The 1300 series electrified rim exit bar features a patented latch that rotates to engage and grip the specially designed strike. This unique interlocking electrified grip action secures the door to the jamb without conventional roller strikes or retracting latches. This patented design increases the security for operators without sacrificing life safety. All RCI 1300 series devices re-latch and have Camlock and cylinder dogging available (for non-fire labeled doors).

  • Warranty: 3 Year Limited Warranty

Detalles del producto

  • Continuous-duty solenoid provides a remote unlock feature for controlled entry
  • Field-selectable 12/24 VDC (800mA @ 12VDC, 400mA @ 24VDC)
  • Weather resistant for outdoor use
  • All devices re-latch
  • Camlock and cylinder dogging available (for non-fire labeled doors)
  • Choice of 3 alarm modules
  • Two standard bar lengths are offered – can be field cut for custom lengths
  • Non-handed
  • High security, exceeding a 1" dead bolt
  • Made in the USA
  • 3 Year Limited Warranty

Detalle técnicos

Dimensions: 2-1/2"H x 3-5/8"D (63.5mm x 92mm)

  • UL certified ANSI/BHMA A156.3-2008, Grade 1
  • UL Listed Fire Exit Hardware, 3 hour fire-rating
  • UL Listed Panic Hardware
  • Conforms to Positive Pressure Standards UL 10C & UBC 7-2
  • Accepted by NYC MEA 337-92M

Componentes

Optional

  • SS1A-10/20/30*– Signal Switch for models with alarm modules (SPDT)
  • SS2A-20/30* – Signal Switch for models with alarm modules (2SPDT)
  • LMS – Lock Monitor Switch. Rated 5A, 250V DC

Accessories

  • DDS - Double door strike, black oxide finish
  • SS1 - Signal switch SPDT
  • SS2 - Signal switch 2SPDT
  • SS1W - Signal switch SPDT weather-proof with mounting hardware

Aplicaciones

  • Use with all types of doors, including narrow-stile aluminum
  • Any exterior door exposed to possible tampering

1300 Series Electrified Rim Exit Devices RCI EAD
