1200 Series Mechanical Rim Exit Bar

The 1200 series mechanical rim exit bar features a patented interlocking latch that rotates to engage and grip the specially designed strike. This unique interlocking grip action secures the door to the jamb without conventional roller strikes or retracting latches. The RCI 1200 series of high security mechanical exit devices resolve the conflict between life safety and security. The RCI 1200 exit device is pre-assembled and can be field cut for undersized doors for easy installation.

Contactar
1200 Mechanical Rim Exit Devices RCI EAD
  • Warranty: 3 Year Limited Warranty

Detalles del producto

  • Weather resistant for outdoor use
  • All devices re-latch
  • Camlock and cylinder dogging available (for non-fire labeled doors)
  • Choice of 3 alarm modules
  • Two standard bar lengths are offered – can be field cut for custom lengths
  • Non-handed
  • High security, exceeding a 1" dead bolt
  • Made in the USA
  • 3 Year Limited Warranty

Detalle técnicos

Dimensions: 2-1/2"H x 3-5/8"D (63.5mm x 92mm)

  • UL certified ANSI/BHMA A156.3-2008, Grade 1
  • UL Listed Fire Exit Hardware, 3 hour fire-rating
  • UL Listed Panic Hardware
  • Conforms to Positive Pressure Standards UL 10C & UBC 7-2
  • Accepted by NYC MEA 337-92M

Componentes

Optional

  • SS1A-10/20/30*– Signal Switch for models with alarm modules (SPDT)
  • SS2A-20/30* – Signal Switch for models with alarm modules (2SPDT)
  • LMS – Lock Monitor Switch. Rated 5A, 250V DC

Accessories

  • DDS - Double door strike, black oxide finish
  • SS1 - Signal switch SPDT
  • SS2 - Signal switch 2SPDT
  • SS1W - Signal switch SPDT weather-proof with mounting hardware

Aplicaciones

  • Use with all types of doors, including narrow-stile aluminum
  • Any exterior door exposed to possible tampering
1200 Mechanical Rim Exit Devices RCI EAD
