Product Summary
The 946 & 950 push plates are ideal for push to open door automation applications. The RCI 946 features a square design with three sizing options (4-1/2”, 4-3/4”, & 6”) for easy aesthetic matching and flexibility in button visibility. The RCI 950 is a round push plate design with a standard 4-1/2” and a larger 6” option. These stainless-steel push plates meet the highest construction and performance standards for dependability in a broad range of door automation applications.
Also available is the RCI T2T (touch to touchless) conversion modules. These modules are designed to convert existing Stainless Steel actuators into a touch-free solution (eg. RCI 946/950)
- Warranty: Lifetime Limited Warranty
- T2T touch free conversion module also available (Converts existing Stainless Steel actuators into a touch-free solution eg. RCI 946/950)
Product Details
946 Square Push Plate
- Available in three sizes
- Momentary (SPDT) switch operation, DPDT accessory kit available
- Tamper-resistant
- Brushed Stainless Steel (32D) finish
- Lifetime Limited Warranty
950 Round Push Plate
- 4-1/2" buttons designed for 2" x 4" (51mm x 102mm) switch boxes and 6" buttons designed for 4" x 4" x 1-1/2" (102mm x 102mm x 38mm) junction boxes
- Available in two sizes
- Momentary (SPDT) switch operation, DPDT accessory kit available
- Tamper-resistant
- Brushed Stainless Steel (32D) finish
- Lifetime Limited Warranty
T2T Retrofit Contactless Module
- Converts existing Stainless Steel ctuators into a touch-free solution
- Will convert other push plate actuators (with no added features or secondary attributes already in use)
- Easy to install and use
Technical Details
946 Square Push Plate
Dimensions: 4-1/2" Sq. (114mm)
4-3/4" Sq. (121mm)
6" Sq. (152mm)
950 Round Push Plate
Dimensions: 4-1/2" Dia. (114mm)
6" Dia. (152mm)
Components
946 Square Push Plate
Accessories
- 9466SUR - Surface-mount box for 6" push plate
- 946475SUR - Surface-mount box for 4.75" push plate
- 94645SUR - Surface-mount box for 4.5" push plate
- 9466FLU - Flush mount box for 6" push plate
- 946475FLU - Flush mount box for 4.75" push plate
- 946475WR - Weather ring for 4.75" push plate
- 946DGPLATE - Back plate for double gang electrical box
- 9464PLAST - Double gang mount box
- P94/5DMO - DPDT accessory kit
950 Round Push Plate
Accessories
- 95045SUR - Surface-mount box for 4.5" push plate
- 9506SUR - Surface-mount box for 6" push plate
- 95045FLU - Flush mount box for 4.5" push plate
- 9506FLU - Flush mount box for 6" push plate
- 950ESC45 - Escutcheons for 4.5" push plate
- 950ESC6 - Escutcheons for 6" push plate
- 946DGPLATE - Back plate for double gang electrical box
- 9464PLAST - Double gang mount box
- P94/5DMO - DPDT accessory kit
T2T (touch-to-touchless) conversion module is available
The RCI T2T Retrofit Contactless Module (RCM) is an innovative and affordable module designed to convert any standard wired push plate actuator to become a wireless touch-to-touchless (T2T) actuator.
Ideal for converting stainless steel actuators (eg: RCI 946-950) to touch-free. Simply install the RCM module to the operator and/or push-plate actuator to instantly convert it to a touchless door actuator.
Applications
- Handicap Areas
- Vandal-Prone Areas
- Vestibules
- Storefront
- Commercial
- Industrial
- Health Care
