Product Summary
The DE8310 Delayed Egress all-in-one lock can detect when pressure is applied to a door and can be field selected with a release delay of 15 or 30 seconds. This perimeter door solution is unique in that there is no need to replace existing door hardware, making it an easy and affordable access solution. The RCI DE8310 includes an external alarm sounder, keyswitch for reset and override, and a building code sign for single outswinging doors. The RCI DE8310-S includes a built-in sounder rather than the external sounder in the base unit. This electromagnetic lock series can be monitored locally or remotely through relay outputs. It is ideal for applications requiring loss prevention, life safety, and traffic control.
- Energy: 490mA Auto-Sensing 12-24VDC (Base unit, max at 12VDC)
- Strength: Up to 1,200lbf Holding Force
- Warranty: 5 Year Limited Warranty
- Mode: Fail-Safe
- Fire-Rated: CAN/ULC S104 UL 10C 1-1/2-Hour
- Monitoring: Local & Remote Relay Outputs & Optional Built-In Sounder
Product Details
- Built-in sensor detects when pressure is applied to outward swinging doors – no need to replace existing door hardware
- Field-selectable 15 or 30 second release delay with field-selectable 0 to 3 second nuisance delay
- Unique highly visible red/green light panel indicates status of door (local)
- Includes 960 Keyswitch for reset and override, Building Code Sign and base unit (DE8310) includes a 914 External Sounder
- Dry contact SPDT and DPDT relays provided for local and/or remote monitoring
- Keyhole mounting for ease of installation
- Convenient plug-in wiring harnesses
- Easy-access wiring cavity
- Stabilizing 4-bolt “drop stop” mounting
- Surge protection
Technical Details
DE8310
Dimensions: 10-13/16"W x 2-7/8"H x 2-1/8"D (275mm x 73mm x 54mm) – Includes 1/4" (6mm) mounting bracket
DE8310S
Dimensions: 11-3/4"W x 2-7/8"H x 2-1/8"D (299mm x 73mm x 54mm) – Includes 1/4" (6mm) mounting bracket
Armature Plate: 7-7/16"W x 2-3/8"H x 5/8"D (190mm x 61mm x 16mm)
Shared Technical Information
- Provision for IBC, SBC, NFPA101, UBC, BOCA or NBC of Canada compliance
- Designed to overcome residual magnetism
- Hardened steel armature nut
- Includes self-drilling Teks® fasteners
- Includes 5/8" (16mm) armature plate
- Brushed Anodized Aluminum (28) finish
- Ability to synchronize up to 4 doors (with or without mullion) using a converter.
- Please request further details (Custom applications that require synchronization of 3 or 4 doors will require special AHJ approval)
- UL 294 Special Locking Arrangements Component (6th Edition)
- ULCS533 Special Locking Arrangements Components (4th Edition)
- CAN/ULC S104 Auxiliary Locks Listed for fire doors rated up to 1-1/2-hour
- UL 10C Auxiliary Locks Listed for fire doors rated up to 1-1/2-hour
- Patent #'s: US 8,292,337 Canada 2,632,243
Components
Optional:
S - Built-In Sounder
Built-in sounder pulses slowly during the short nuisance delay and sounds steady through the release delay and will continue until reset. If forced open before the set release delay has lapsed, the sounder cannot be turned off without switching the system power off.
Accessories
BC1M-30 30 Second Building Code Sign
Applications
- Health Care Facilities
- Retail & Wholesale Centers
- Airports
- Public Transit Buildings
- Museums & Galleries
