Product Summary
Mechanical combination lock with dead bolt.
User lock approx. 38,000, master lock approx. 78,000 theoretical variations.
The user sets by means of the 4 knobs a combination to open or to close the lock. If necessary, the combination can be decoded with the decoding key and the lock can be opened.
Application areas are hotel safes, cloakrooms and left luggage lockers. Adhesive labels with operating instructions make the simple use of the lock clear to the user.
Product Details
Approvals/Certificates
- Without any approvals/certificates
Lock
- User lock: 4 knobs plastic, black, 14 settings (0-9, A-D) each
- Decoding lock: 6 levers, changeable lock, plastic/steel
- Decoding key retained when in open position
- Lock case, bolt and knobs plastic, black, throw 20 mm
Admissible mounting positions
- Right or left hand lock (mounting upside down), opening clockwise
NB:The mounting positions “bolt up, bolt down, bolt right” are only admissible for the mounting method “fitting plate” (option MGS). These mounting positions are not admissible for the “coin function” .
Technical Details
Lock
- Quick-Combi K - standard - Order number: 81021
Mounting method
- Direct screwing (4 locating discs and carrying brackets included in delivery)
- Mounting plate or welding bolts (4 slotted nuts included in delivery)
- Fitting plate (4 slotted nuts, locating discs and carrying brackets included in delivery)
Options
- Coin function (for 1 EUR, coin as pledge)
- Coin function (for 2 EUR, coin as pledge)
- Coin function (available for different currencies and jetons, coin as pledge)
- Decoding lock in works locking mode
- Lock set to a given master lock
Accessories
- Mounting plate 2 mm thick, with stud bolts - Order number: 3 102 000 230
Fitting plate 2 mm thick, stainless steel, in front of the door, threaded bolts M5:
- Horizontal fitting, suitable for door thickness up to 2 mm, bolt left - Order number: 3 102 900 002
- Horizontal fitting, suitable for door thickness up to 13 mm, bolt left - Order number: 3 102 900 003
- Horizontal fitting, suitable for door thickness up to 2 mm, bolt right - Order number: 3 102 900 005
- Horizontal fitting, suitable for door thickness up to 13 mm, bolt right - Order number: 3 102 900 004
- Vertical fitting, suitable for door thickness up to 2 mm, bolt up - Order number: 3 102 900 001
- Vertical fitting, suitable for door thickness up to 13 mm, bolt up - Order number: 3 102 900 006
- Vertical fitting, suitable for door thickness up to 2 mm, bolt down - Order number: 3 102 900 007
- Vertical fitting, suitable for door thickness up to 13 mm, bolt down - Order number: 3 102 900 008
