Product Summary
The conical number knob set LA GARD 2107 is used to operate mechanical combination locks.
Product Details
Dial and ring combination
- External diameter 76 mm
- Die-cast with satin chrome finish
- Hardware pack: 2 screws 8-32 x 5/16 PH
- (8mm), flat screw head
Scale
- Front reading
- Separate change and opening marking
Spindle
- Thread UNS 5/16"-40, die-cast
- Projecting 102 mm
- Usable length: 79 mm for 3 wheels,
- 73 mm for 4 wheels
- Dial splined on 43
- Suitable for all LA GARD mechanical combination locks
Weight
- Approx. 200 g
Technical Details
Options
- Spindle, steel, projecting 192 mm (usable length: 169 mm for 3 wheels, 162 mm for 4 wheels) - Option code: SPV192
- Surface black with white numbers - Option code: OSW
Accessories
- Screw M4 x 8 mm (2 screws are required per dial)
