KES200Z: Non monitored electric strike

The dormakaba KES200Z is an economical strike designed for use with a large selection of mortice, key-in-knob and key-in-lever type locks in both timber and metal frames. The KES200Z also offers variable voltage from 12VAC/DC to 28VAC/DC as well as a fast and convenient interchangeable fail safe/ fail secure function (changeable on site).
Construction materials include a solid zinc alloy housing and a stainless steel keeper. The unit comes pre-drilled for the optional extension lips. Also included in the pack is an installation kit for metal frame installations.

The KES200Z is certified to RCM standards under ACMA.

Get in touch
KES200Z

Product Details

  • Fail safe/ fail secure interchangeable
  • Variable voltage 12 - 28VAC/DC
  • Suits latch depth up to 15mm
  • Pre-drilled for optional extension lips
  • Includes mounting tabs for metal frames
  • Tested to 1 million cycles

Dimensions

  • 175L x 44W x 27D (mm)

Optional Accessories

  • Lip extension, 25mm
  • Lip extension, 50mm

Technical Details

  • Operating voltage variable 12-28VAC/DC
  • Voltage tolerance +/- 15%
  • Current Draw: 12VDC/230mA, 28VDC/140mA (at temperature 20 degrees celsius)
  • Operating temperature: -10 to 45 degrees celsius
  • Humidity: 0 - 95% non-condensing
  • CE Approved
