Product Summary
The Skyfold Mirage is a glazed partition with an STC of 33 (RW 33) and finish options like frosted glass, plexi glass, bullet prrof glass, & even solid panels. The Mirage creates rooms that still feel airy and connected but that are private enough for meetings, collaboration, classes, autonomous work, and so on.
Skyfold Mirage allows for hallways and windows to lend their light to otherwise isolated spaces.
- Retracts into the Ceiling to Conserve Floor Space
- Acoustic Properities 33 STC
- No Floor Tracks
- Fully Automatic
- Easy-to-Use Turn-Key or Keypad Operation
- Quiet Operation
- Flat, Rigid and Lightweight
- Variety of Glass and Plexiglass Options to Meet Your Design Needs
- Equipped with an Infrared Safety System
- Made to Last
Product Details
Skyfold Mirage can be inserted with Clear laminated glass, plexiglass, Lexan, bullet proof glass, frosted glass and more.
Technical Details
- Acoustic Rating of System –STC 33 (RW 33)
- Acoustic Rating of Panels – STC 36 (RW 36)
- Max. Wall Height - 7315mm
- Max. Wall Length – Unlimited Length
- Weight: 36.6 kg/m2
- Ceiling Space Required for Storage (approx.*) – Varies from 965mm to 1450mm
- Ceiling Pocket Width (approx.*) – Varies from 1105mm to 1550mm
- Uses aircraft grade wire cables sized for a high safety factor
- Bottom leading edge equipped with an obstruction sensor and auto-reverse.
- Finish Options - A Variety of Single Laminated Glass Options, such as Plexiglass, Lexan©, Bullet-Proof Glass, Frosted Glass. Standard Frame Finish: Clear Anodized Aluminium (Custom Frame Finishes Available Upon Request).No Floor & Wall Tracks
- Wall Track are used
- Back-Up Operation
- Auto-Reverse
- Warranty – for Parts & Labor up to 2Year or 5000 cycles which occurs first. Optional Extended Warranty at request.
Functionalities
Mirage incorporates Skyfold technology with the added luxury of transparency
Components
Clear Anodized Aluminium (Custom Frame Finishes Available Upon Request).
Clear laminated glass, plexiglass, Lexan, bullet proof glass, frosted glass options available.
Uses aircraft grade wire cables sized for a high safety factor
Each cable is lifted by a separate cable drum
Bottom leading edge equipped with an obstruction sensor and auto-reverse
Applications
The space division solution that doesn’t compromise on an open concept design plan
