Simplex 900 - Deadbolt/Spring Latch

Simplex Mechanical Pushbutton Locks eliminate problems and costs associated with issuing, controlling, and collecting keys and cards.

Mechanical pushbutton lock provides fully mechanical access control, while allowing free egress at all times by interior thumbturn. Deadbolt models must be manually relocked. Deadlocking spring latch models automatically relock each time the door closes. This fully mechanical lock eliminates the material and labor expense of battery replacements, has a single access-code and is programmed via the keypad without removing the lock from the door.

Get in touch

Simplex 900 Series 902/4/7/19-04 Satin Brass

Product Details

No Battery: Fully mechanical lock eliminates the material and labor expense of battery replacements

Locking Device Options:

Deadbolt—1" throw, manual relock
Deadlocking Latch—⅝" throw with automatic relock

Number of Codes: Single access code—one easy-to-manage code for all users

Programming: Lock is easily programmed via keypad without removing lock from the door

Handing: Field reversible latch; invert the lock for right-hand doors; roman numerals are easily read in either orientation

Optional Key Override: Can be used to override the lock combination and gain access using a key. Allows facilities to initiate or maintain a master-keyed security system (keyed alike or keyed differently). Override models can be ordered with or without a cylinder.

Options:

Add panic bar release kit (select models)
Keyed alike option available (select models)
Latch holdback (select models)
D.O.D. compliant (select model)
Substitute a 2½" (64 mm) lever in place of the standard inside thumbturn (select models)

Operation Modes:

Pushbutton Access
Latch Holdback—keeps latch retracted to allow access with combination (select models)

Economical: A cost effective access control solution

Technical Details

Construction: All metal cast front housing, force-resistant, clutch-protected thumbturn, metal exterior trim plate

Numeric Keypad: Vandal resistant, solid metal pushbuttons

Handing: Field reversible latch; invert the lock for right-hand doors; roman numerals are easily read in either orientation

Backset: 2 9⁄16" (65 mm) for outswing doors, 2½" (64 mm) for inswing doors

Door Thickness:

1⅜" (35 mm) to 1½" (38 mm)
1¾" (44 mm) to 2⅛" (54 mm)
Model 929: Lockset for D.O.D. standards, 1¾" (44 mm) to 2⅛" (54 mm) only
Model 927: Lockset for D.O.D. standards, 1⅜" (35 mm) to 1½" (38 mm) only

Latch: 1" (25 mm) deadbolt; ⅝" deadlocking spring latch

Strike: Includes strike plate for outswing doors, cast box strike for inswing doors; metal door frames require the optional surface mortise box strike or use of an adapter kit

Durability: Weather resistant

Warranty: 1-year warranty

Finishes:
