Product Summary

The 2 series are versatile, all-in-one, electric strikes that combine strength and convenience in a sleek design. The RCI F2164 & 2364 strikes feature an adjustable deadbolt keeper and deadlatch ramp allowing them to flexibly work with most locks. The "Saw-tooth Adjustment Locator" makes installation simple. It allows the installer to move the deadbolt keeper, or plug and deadlatch ramp vertically to align with a wide variety of mortise locks with offset latches. It also includes a trim plate to cover up an irregular frame cut-out. Everything you need for the strike is in the box, including a faceplate for centerline latch entry.

  • Energy: 375mA Field-Selectable 12/24VDC, 12-24VAC (Max at 12VDC) (12-24VAC not available with 2364 model)
  • Strength: 1,500lbf Static 70ft-lb Dynamic
  • Endurance: 500,000 Cycles
  • Mode: Fail-Secure & Fail-Safe
  • Fire-Rated: Optional 3-Hour Model Available (Fire-rated (F) model only, 3-hour for single swing, 90-minutes for standard pair of doors)
  • Latch Monitor: Plug-In Latch Monitor Accessory Available

Product Details

  • Versatile strike designed to work with most locks
  • Accommodates 1/2" (12.7mm) to 3/4" (19mm) latch projection
  • Adjustable deadbolt keeper and deadlatch ramp
  • Accommodates up to 1" deadbolt (night-latch function only, bolt will not release)
  • Plug-in wire connectors
  • Runs cool – solenoid design prevents keeper from heating up
  • Trim plate included to cover up irregular frame cut-out
  • Stainless steel ensures superior strength and creates a sleek aesthetic
  • Includes two keeper shims – 1/16" (1.5mm) and 1/8" (3mm) –for horizontal adjustment for misaligned frames (unique sliding design)
  • Non-handed
  • 375mA Field-Selectable 12/24VDC, 12-24VAC (Max at 12VDC) (12-24VAC not available with 2364 model)
  • 1,500lbf Static 70ft-lb Dynamic
  • 500,000 Cycles
  • Fail-Secure & Fail-Safe
  • Optional 3-Hour Model Available (Fire-rated (F) model only, 3-hour for single swing, 90-minutes for standard pair of doors)
  • Plug-In Latch Monitor Accessory Available
  • 10 Year Limited Warranty

Technical Details

Faceplate: 1-1/4"W x 4-7/8"H (32mm x 124mm)
Insert Depth: 1-3/4"D (45mm)

  • Factory tested to over 2-million cycles of operation
  • Brushed Stainless Steel (32D) finish
  • UL 294 Listed for Access Control Unit Accessory (6th Edition)
  • UL 1034 burglary-resistant Listed
  • UL 10C, 3-hour fire-rating Listed3
  • CAN/ULC S104, 3-hour fire-rating Listed3
  • California State Fire Marshal Listed (CSFM: 3776-2275:0502) (Fire-rated (F) model only, 3-hour for single swing, 90-minutes for standard pair of doors)
  • Certified to ANSI/BHMA standard A156.31, Grade 1, endurance 500,000 cycles
  • Patent #: US 9,580,935
  • Patent #: Cdn 2,850,072

3For fire-rated models

Components

Accessories

  • F2LM - Latch monitor plug-in kit (2A @ 24VDC)
  • 2FP - Filler plate (for use when replacing discontinued 2 Series models)
  • F2-19 - Centerline faceplate, 1-3/8"W x 9"H (35mm x 229mm), 32D finish
  • F2-29 - Offset faceplate, 1-3/8"W x 9"H (35mm x 229mm), 32D finish
  • 940-LG High profile latch guard 32D

Applications

  • Commercial Centers
  • Industrial Buildings
  • Educational Facilities
  • Retail Outlets
  • Health Care Facilities
  • Office Complexes

F2164 Electric Strikes RCI EAD
F2-19 Centerline FacePlate
F2-29 Offset Faceplate
