RCI 0161 3/4" Semi-Mortise Rim

The 0161 is a 3/4" semi-mortise electric strike that is designed to operate with Pullman latch rim exit devices. The stainless-steel finish creates a sleek attractive architectural appearance. The slotted horizontal holes on the faceplate allow for easy and secure mounting during installation and correct alignment with the exit device. It features a hazard-free radius design.

0161 Rim Strikes Electric Strikes RCI EAD
  • Energy: 200mA 12VAC/VDC Or 24VAC/VDC (Max at 12VDC)
  • Strength: 1,500lbf Static 70ft-lb Dynamic
  • Endurance: 500,000 Cycles
  • Mode: Fail-Secure
  • Warranty: 5 Year Limited Warranty

Product Details

  • Semi-mortise rim strike designed for use with Pullman latch rim exit devices
  • Accommodates 1/2" to 3/4" (13mm–19mm) latch projection
  • Ensures proper latch alignment with horizontal adjustment
  • Stainless steel ensures superior strength and creates a sleek aesthetic design
  • Lockdown holes for secure mount
  • Non-handed
  • 200mA 12VAC/VDC Or 24VAC/VDC (Max at 12VDC)
  • 1,500lbf Static 70ft-lb Dynamic
  • 500,000 Cycles
  • Fail-Secure
  • 5 Year Limited Warranty

Technical Details

  • Dimensions: 1-3/4"W x 9"H x 1-5/8"D (45mm x 229mm x 41mm)
  • Brushed Stainless Steel (32D) finish
  • UL 1034 burglary-resistant Listed
  • Endurance 500,000 cycles

Components

Accessories

  • 0161DDH - Double door housing, SPC finish (SPC=Silver Powder Coat)

​Note: UL 1034 Burglary-resistant listing does not apply with use of 0161DDH.

Applications

  • Commercial Centers
  • Industrial Buildings
  • Educational Facilities
  • Retail Outlets
  • Health Care Facilities
  • Office Complexes
0161 Rim Strikes Electric Strikes RCI EAD
