Product Summary

Partly changeable safe deposit lock with dead bolt.

Combination lock 17,600, key lock 46,7000 theoretical variations.

This safe deposit lock combines the features of a combination lock and a key lock. Only after a valid combination has been set using the three knobs, can the user open the lock with the key. The combination is changed via a slide unit at the back of the lock.

3-way closure is available as an option.

Product Details

Approvals/Certificates

  • Without any approvals/certificates

Lock

  • Combination lock
    • 3 die-cast knobs, nickel-plated, 26 setting marks (A-Z) each
    • Set combination can be seen at back of lock
    • Combination change via slide unit at back of the lock
  • Key lock
    • 6 levers, electrolytic galvanised steel
    • Key retained when in open position
  • Die-cast lock case and bolt, throw 11 mm
  • Suitable for doors from 7 to 15 mm
  • Weight approx. 1,150 g

Admissible mounting positions

  • Right hand lock, opening clockwise

Technical Details

Lock

  • Combi-Deposit - standard - Order number: 81033

Options

  • Lock case and bolt surface treated - Option code: SRO
  • Lock with 3-way closure - Option code: SDS
  • Bolt with 1 M6 thread - Option code: RGW1x6
  • Bolt with 2 M4 threads - Option code: RGW2x4
  • Key guide projecting 2 mm, aluminium EV1 anodised, Ø 29.5 mm, riveted - Option code: SFA002
  • Key guide projecting 3.5 mm, aluminium EV1 anodised, Ø 29.5 mm, riveted - Option code: SFA3.5
  • Key guide projecting 8 mm, aluminium EV1 anodised, Ø 29.5 mm, riveted - Option code: SFA008
  • Admissible mounting position: lock vertical, right hand lock, opening clockwise - Option code: SBS

Accessories

  • Mounting plate 3 mm thick with 4 M6 threaded bushings, screws and securing rings - Order number: 3 118 000 380
    • Optional with spot-welded manganese steel plate 1.5 mm thick - Order number: 3 118 000 160
  • Mounting plate 3 mm thick, with 4 M6 threaded bushings, screws and securing rings (only for use in conjunction with option SDS) - Order number: 3 118 000 150
    • Optional with spot-welded manganese drilling plate 1.5 mm thick (only for use in conjunction with option SDS)  - Order number: 3 118 000 370
  • Manganese steel plate 1.5 mm thick - Order number: 2 130 001 410

Combi-Deposit - Keys with square bow
