Product Summary
MUNDUS Patch Fittings have been discontinued. Limited parts and support may be available. Download support material below or contact a support representative for additional information using one of the phone numbers from the contact section.
- Clean design, with no visible fasteners
- Wide range of finishes and materials
- Supports glass thickness ranging from 5/16" (8) to 7/8" (22)
- Max. door panel weight of 440 lbs
- Suitable for tempered laminated glass (TLG)
- Adjustable and durable - over 1,000,000 test cycles
Product Details
Freedom of versatility
MUNDUS patch fittings can be adjusted in multiple directions, even after installation:
- Fast installation, fittings can be adjusted at any time, offering pivot point and flush alignment, as well as zero position.
- Multi-directional adjustability - left and right as well as around the axis of rotation
- Glass thickness is adjusted by using screws in the patch fitting body rather than requiring additional gaskets
- Easy to retrofit and integrate into existing systems
Elegant, sharp design—high quality materials
MUNDUS expands capabilities of patch fitting doors:
- Increased weight capacity up to 440 lbs.
- Supporting tempered laminated glass (TLG)
- Glass thickness can range from 5/16" (8) to 7/8" (22), without changing gaskets
Durable and functional
MUNDUS and tempered laminated glass (TLG) —a combination with impressive advantages:
- A high level of user safety, even with large glass doors
- Decreased noise levels enabled by integrating noise-reducing laminate
- Glass doors as design elements utilizing decorative TLG
Technical Details
More planning freedom and security
- Seamlessly accepts glass thicknesses ranging from 8 to 22 mm 5/16" (8) to 7/8" (22)
- Secure use of laminated-safety glass (residual load-bearing capacity, design or sound-insulation film)
- Glass-door leaf weight up to 440 lbs. (200 kg)
- Durability: 1,000,000 cycles
You can find additional technical information in the technical documents for download.
Applications
For indoor and outdoor use, e.g.
- Doctor's offices
- Hotel rooms
- Schools and universities
- Shop fronts
- Office rooms
- Private residences
