RCI 910TC Series Touchless Actuators for use with automatic doors

The RCI 910TC Series touchless switches is designed for touchless door activation in any facility. It functions by triggering activation of automatic door openers by hand gesture or use of a remote fob. It can make the difference when it comes to a clean, hygienic facility. The 910TC Series is ideal for use in healthcare facilities, restaurants, schools, offices and restrooms by minimizing touchpoints.

Get in touch

Energy: 12-24VDC 50/25mA
Range: 1" to 2" (30mm - 50mm)
Switch Mode: Momentary
Switch Configuration: SPDT
Also available 910TC-HC – with alternate icon on faceplate and 910TC-SS stainless steel faceplate
Available with optional remote fob and receiver
Available in standard single-gang (910TC) or mullion (narrow 910NTC) models
Available with French faceplates
Available with Stainless Steel faceplates
Warranty: 3 Year Limited Warranty

Product Details

Aesthetically pleasing designs.
Hands-free – helps reduce the spread of germs and bacteria.
Adjustable detection zone to reduce unwanted activations.
When the device is activated, the indicator light (waving hand) will change color.
Secondary Normally Open (NO) mechanical switch in the event of a power loss.
Selectable unlock times (1-63 seconds).
Available remote control to trigger switch remotely.
May be purchased as a kit (910TC-WRM-WRB). Includes 910TC Switch, 910TCWRM Remote Receiver Module and 910TC-WRB Remote Transmitter.
Meets ADA compliance to ANSI/BHMA A156.19
(Always check local building codes for compliance in your area)
