Code-Combi K - Electronic Combination Safe Lock

Electronic combination lock with dead bolt for safes CEN 0-II.

Approx. 1 million variations.

The user can programme max. two 6-digit codes.

The lock features power saving solenoid technology. Under defined conditions it is possible to achieve approx. 30,000 opening operations with one battery.

3-way closure is available as an option.

İletişime Geçin

Electronic Combination Safe Lock Code- Combi K

Ürün Detayları

Approvals/Certificates

EN 1300, ECB-S, VdS class 1, GOST class A, IMP class A

Codes

2 User codes, 6 digits
1 dual mode (2 x 6 digits)
1 user code (6 digits)
1 dual mode (2 x 6 digits)

Power supply

1 x 9 volt block battery (not included in delivery)

Lock

Die-cast lock case and bolt, throw 20 mm
Electromagnetic bolt release
Bolt applicable for 2 M4 threads (holes 3.1 mm)
Integrated battery case
Weight approx. 600 g

Admissible mounting positions

Right hand/left hand lock (upside down mounting), opening clockwise

NB: The mounting positions "bolt up, down or right" are not admissible for the options “coin function” and “activation-key function”.

Teknik detaylar

Electronic combination lock

Code-Combi K - standard (safe lock version) - Order number: 82021

Mounting position lock and input unit
(Please specify option code "mounting position" + "spindle"!)

Input unit horizontal (key pad right)
Lock horizontal (bolt left)
Option code: TRL
Input unit horizontal (key pad right)
Lock vertical (bolt up)
Option code: TRO
Input unit horizontal (key pad right)
Lock vertical (bolt down)
Option code: TRU
Input unit horizontal (key pad left)
Lock horizontal (bolt right)
Option code: TLR
Input unit horizontal (key pad left)
Lock vertical (bolt up)
Option code: TLO
Input unit horizontal (key pad left)
Lock vertical (bolt down) *
Option code: TLU*
Input unit vertical (key pad up)
Lock horizontal (bolt left)
Option code: TOL
Input unit vertical (key pad up)
Lock horizontal (bolt right)
Option code: TOR
Input unit vertical (key pad down)
Lock horizontal (bolt left)
Option code: TUL
Input unit vertical (key pad down)
Lock horizontal (bolt right)
Option code: TUR
Input unit vertical (key pad down)
Lock vertical (bolt up) *, **
Option code: TUO*,**

NB:
* Not available for spindles with max. usable length of 122 mm!
** Not available for spindles with max. usable length of 72 mm!

Spindles (Please add to option code “mounting position”. Example: TRL007)

Spindle length [mm]: 34
Usable length [mm] (distance lock - input unit): 7
Option code: 007
Spindle length [mm]: 45
Usable length [mm] (distance lock - input unit): 17
Option code: 017
Spindle length [mm]: 50
Usable length [mm] (distance lock - input unit): 22
Option code: 022
Spindle length [mm]: 60
Usable length [mm] (distance lock - input unit): 32
Option code: 032
Spindle length [mm]: 100
Usable length [mm] (distance lock - input unit): 72
Option code: 072
Spindle length [mm]: 150
Usable length [mm] (distance lock - input unit): 122
Option code: 122

NB: Further lengths are available on request.

Lock

Lock case and bolt surface treated - Option code: SRO
Lock with 3-way closure, throw 12 or 20 mm - Option code: SDS
Bolt with 2 M4 threads - Option code: RGW2x4
Blocking drive pin (for bolt work 84031 with accessories ”blocking slide”) - Option code: SSD

Accessories

Screw set: 2 cheese head screws, galvanised, DIN 84 - BSW ¼“ x 29 mm - 4.8, 2 cheese head screws, galvanised, DIN 84 - BSW ¼“ x 32 mm - 4.8, securing rings - Order number: 3 118 000 510
Mounting plate 2 mm thick, 4 M5 threaded bushings, with screw nuts and securing rings - Order number: 3 118 000 140
Mounting plate 2 mm thick with manganese steel plate 1.5 mm thick, with 4 M5 threaded bushings, screw nuts and securing rings - Order number: 3 118 000 130
9 volt alkaline block battery - Order number: 0 516 000 000
