SVP / M-SVP-S Controls

The SVP and M-SVP control units enable the use of dormakaba motor locks with a full range of functions. Depending on the model and in addition to the conventional activation functions of short-term and permanent door releases via access control systems or intercoms, it is possible to trigger further functions, such as the latch locking during day function, automatic drives for actuation impulses, signals for alarm systems, electrical disconnections of access control / entry for GMA, etc. It is also possible to analyse various types of feedback regarding the condition of the lock.

Intrați în legătură

For the activation of dormakaba motor locks
Feedback about lock condition
Connection of automatic drives
Version-dependent special functions
Special functions, e.g. timer, networking, etc.
Versions with or without power supply unit

Product Details

SVP-S 4x DCW^®

Control unit for operating SVP 2000 DCW^® or M-SVP 2200 DCW^® emergency-escape locks with automatic locking action in stand-alone mode. Control unit and lock are connected via the DCW^® system bus.
With freely programmable inputs and outputs to control door release functions or for the output of feedback, as well as an integrated timer and LON/LAN connection possibility. Available in different equipment variants.

M-SVP 2000 Control

Optional external surface-mounted control with power supply unit for M-SVP 2000 multipoint locks, which can be used instead of the internal control accompanying the locks. With inputs and outputs to control door release functions (incl. latch locking during day function) and for the output of feedback.

M-SVP 3000 Control unit

Surface-mounted control with power supply unit to activate M-SVP 3000 and M-SVP 3500 multipoint locking systems. With inputs and outputs to control door release functions and for the output of feedback.
