Electronic combination lock with dead bolt.

The Code-Combi KL for changing users offers approx. 10,000 variations. The user needs the appropriate 4-digit code to open and close the lock. This can be chosen differently every time it is locked. If required the lock can be opened at any time with an 8-digit master code.

Application areas are hotel safes, cloakrooms and left luggage lockers.

tuotteen yksityiskohdat

Approvals/Certificates

  • Without any approvals/certificates

Input unit

  • Plastic, basalt grey (RAL 7012), grey blue (RAL 5008)
  • Foil keypad with 2 LEDs and buzzer
  • Connection cable with plug
  • Device for emergency power supply
  • Weight approx. 100 g

Power supply

  • 1 x 9 volt block battery (not included in delivery)

Lock

  • Die-cast lock case and bolt, throw 20 mm
  • Electromagnetic bolt release
  • Bolt prepared for 2 M4 threads (holes 3.1 mm)
  • Integrated battery case
  • Weight approx. 600 g

Admissible mounting positions

  • Right hand/left hand lock (upside down mounting), opening clockwise

NB: The mounting positions "bolt up, down or right" are not admissible for the options “coin function” and “activation-key function”.

Tekniset yksityiskohdat

Electronic combination lock

  • Code-Combi KL - standard (locker/hotel lock version) - Order number: 82011

Mounting position lock and input unit
(Please specify option code "mounting position" + "spindle"!)

  • Input unit horizontal (key pad right)
  • Lock horizontal (bolt left)
  • Option code: TRL

  • Input unit horizontal (key pad right)
  • Lock vertical (bolt up) *
  • Option code: TRO *

  • Input unit horizontal (key pad right)
  • Lock vertical (bolt down) *
  • Option code: TRU *

  • Input unit horizontal (key pad left)
  • Lock horizontal (bolt right) *
  • Option code: TLR *

  • Input unit horizontal (key pad left)
  • Lock vertical (bolt up) *
  • Option code: TLO *

  • Input unit horizontal (key pad left)
  • Lock vertical (bolt down) *, **
  • Option code: TLU *,**

  • Input unit vertical (key pad up)
  • Lock horizontal (bolt left)
  • Option code: TOL

  • Input unit vertical (key pad up)
  • Lock horizontal (bolt right) *
  • Option code: TOR *

  • Input unit vertical (key pad down)
  • Lock horizontal (bolt left)
  • Option code: TUL

  • Input unit vertical (key pad down)
  • Lock horizontal (bolt right) *
  • Option code: TUR

  • Input unit vertical (key pad down)
  • Lock vertical (bolt up) *, **, ***
  • Option code: TUO *,**,***

NB:
* These mounting positions are not admissible for the coin function and for the activation-key function (see options).

** Not available for spindles with max. usable length of 122 mm!

*** Not available for spindles with max. usable length of 72 mm!

Spindles (Please add to option code “mounting position”. Example: TRL007)

  • Spindle length [mm]: 34
  • Usable length [mm] (distance lock - input unit): 7
  • Option code: 007

  • Spindle length [mm]: 45
  • Usable length [mm] (distance lock - input unit): 17
  • Option code: 017

  • Spindle length [mm]: 50
  • Usable length [mm] (distance lock - input unit): 22
  • Option code: 022

  • Spindle length [mm]: 60
  • Usable length [mm] (distance lock - input unit): 32
  • Option code: 032

  • Spindle length [mm]: 100
  • Usable length [mm] (distance lock - input unit): 72
  • Option code: 072

  • Spindle length [mm]: 150
  • Usable length [mm] (distance lock - input unit): 122
  • Option code: 122

NB: Further lengths are available on request.

Lock

  • Lock case and bolt surface treated - Option code: SRO
  • Lock with 3-way closure, throw 12 or 20 mm - Option code: SDS
  • Bolt with 2 M4 threads - Option code: RGW2x4

Functions

  • Coin function (for 1 EUR coin, coin as pledge) - Option code: EUR001
  • Coin function (for 2 EUR coin, coin as pledge) - Option code: EUR002
  • Coin function for further currencies and jetons on request
  • Activation-key function incl. activation-key (activation-key as a pledge) - Option code: ASA

Adhesive labels

  • Adhesive label: German operating instructions for standard version - Option code: ABD
  • Adhesive label: German operating instructions for coin function - Option code: AMD
  • Adhesive label: German operating instructions for activation-key function - Option code: AAD
  • Adhesive label: English operating instructions for standard version - Option code: ABE
  • Adhesive label: English operating instructions for coin function - Option code: AME
  • Adhesive label: English operating instructions for activation-key function - Option code: AAE

Accessories

  • Screw set: 2 cheese head screws, tin coated, DIN 84 - BSW ¼“ x 29 mm - 4.8, 2 cheese head screws, tin coated, DIN 84 - BSW ¼“ x 32 mm - 4.8, securing rings - Order number: 3 118 000 510
  • Mounting plate 2 mm thick, 4 M5 threaded bushings, with screw nuts and securing rings - Order number: 3 118 000 140
  • Mounting plate 2 mm thick with manganese steel plate 1.5 mm thick, with 4 M5 threaded bushings, screw nuts and securing rings - Order number: 3 118 000 130
  • 9 volt alkaline block battery - Order number: 0 516 000 000

Toiminnot

Functions

  • 1 master code, 1 user code
  • Single mode (master 1 x 8 digits, user 1 x 4 digits)
  • Low voltage detection
  • Wrong try lockout after 3 false codes (1, 2, 4, 8, max. 16 minutes)
  • Acoustical and optical operation support, manipulation indication
